The KC Turbo 302665 is a 6.0-style intercooler retrofit for a 1999.5–2003 7.3 Powerstroke. It is the larger bar-and-plate core and the boots that make it fit the 7.3.
The end tanks are cast aluminum. The core is TIG-welded bar and plate, rated past 150 psi. Four 8-inch multi-layer boots and four constant-tension clamps are in the box. It uses the factory intercooler mounts. The transmission cooler lines have to be moved, or a 6.0 transmission cooler has to go in, or the core will not clear.
It fits 1999.5–2003 Super Duty 7.3 trucks.
Fitment
- 1999.5–2003 Ford 7.3L Powerstroke
- 6.0-style bar-and-plate core
- Cast aluminum end tanks
- Rated past 150 psi
- Four 8-inch boots and clamps
- Transmission cooler lines have to move
A stock 7.3 core is the smaller job. This one is for a tuned truck or a bigger turbo that heat-soaks the factory intercooler.
The KC Turbo 302665 is a 6.0-style intercooler retrofit for a 1999.5–2003 7.3 Powerstroke. It is the larger bar-and-plate core and the boots that make it fit the 7.3.
The end tanks are cast aluminum. The core is TIG-welded bar and plate, rated past 150 psi. Four 8-inch multi-layer boots and four constant-tension clamps are in the box. It uses the factory intercooler mounts. The transmission cooler lines have to be moved, or a 6.0 transmission cooler has to go in, or the core will not clear.
It fits 1999.5–2003 Super Duty 7.3 trucks.
Fitment
- 1999.5–2003 Ford 7.3L Powerstroke
- 6.0-style bar-and-plate core
- Cast aluminum end tanks
- Rated past 150 psi
- Four 8-inch boots and clamps
- Transmission cooler lines have to move
A stock 7.3 core is the smaller job. This one is for a tuned truck or a bigger turbo that heat-soaks the factory intercooler.
Q
Michael • 10/19/2025, 9:09:19 PM
Hi do you guys post to Australia an roughly how much does it cost?
A
10/21/2025, 1:17:52 PM
Roughly $225
Q
Jim Watkins • 10/20/2026, 5:18:42 AM
I’m looking for the boots to complete this upgrade
A
10/20/2026, 1:00:30 PM
The boots are included with this kit. If you've done the upgrade on your own and are only needing the boots then you'll search "7.3L Powerstroke 6.0 Intercooler Swap Boot Kit DieselSite DSIBK6SW"
