The aFe 10-10012 Magnum FLOW Pro 5R is an OE replacement air filter for 1994-1997 Ford 7.3L OBS Powerstroke trucks. It replaces the paper element in the stock airbox with an oiled, washable cotton gauze filter.

Five progressively finer layers of cotton gauze give high airflow, and aFe rates the media at 98.6 percent efficiency on ISO coarse dust. Tall, evenly spaced pleats hold more dirt between cleanings.

• Pro 5R Media: 5 layers of oiled cotton gauze.
• 98.6% Efficiency: aFe ISO coarse dust rating.
• Washable: Clean, re-oil and reuse.
• Bump Seal: Molded urethane seal, no gasket.
• Drop-In Fit: Uses the stock airbox.

Technical Specifications

• Part Number: 10-10012
• Manufacturer: aFe Power
• Media: Pro 5R oiled cotton gauze, 5 layer
• Outside Size: 12.95 x 6.15 in oval
• Flange Inside: 9.73 x 2.92 in
• Height: 6.06 in
• Frame: Polyurethane with bump seal
• Emissions: aFe states no CARB EO number is required
• Warranty: Limited lifetime (aFe)

Vehicle Fitment & Technical Installation Notes

• Fitment: 1994-1996 Ford F-250, 1997 F-250 HD, 1994-1997 F-350 and 1995-1997 F-Super Duty with the 7.3L Powerstroke. It drops into the factory airbox.
• Installation Tip: Clean the airbox and wipe out loose dirt before dropping in the filter. When servicing, use a light, even coat of filter oil so excess oil is not pulled into the intake.
