S1 Amber/Clear Dual Fog LED Pocket Light Kit

Thumbnail Filmstrip of S1 Amber/Clear Dual Fog LED Pocket Light Kit | Baja Designs 447849 Images

Upgrade Your GMC Sierra's Lighting with the Baja Designs Fog Pocket Kit

Maximize your on and off-road visibility with the Baja Designs Fog Pocket Kit, designed specifically for GMC Sierra 2500HD and 3500HD models. This kit seamlessly integrates into your factory fog pocket locations, packing two powerful S1 lights on each side for a total of four. Choose between white or amber light options to suit your needs and style.

Intelligent Lighting Control:

This kit offers smart control options: the lower pair of S1 lights are operated by your factory fog light switch, while the upper pair is activated with your high beams. The included wiring harness is compatible with factory light switches and aftermarket sPOD/Switch-Pros systems, providing flexible installation.

Powerful and Versatile Illumination:

Each S1 light delivers 2,375 lumens of bright, usable light, utilizing a single high-performance LED. The kit includes two S1 Spot lights for long-range visibility and two S1 Wide Cornering lights for enhanced peripheral vision in fog, dust, or cornering situations.

Wide Cornering Pattern: A 42° flattened horizontal beam provides comfortable lighting for near-field visibility in Lighting Zones 1 and 2, ideal for fog, dust, and cornering.
Spot Pattern: A narrow 9° beam focuses light further down the trail or road (Lighting Zones 4 and 5), perfect for complementing Wide Cornering or Driving/Combo lights.

Built to Last:

Like all Baja Designs products, this kit is built to withstand the harshest conditions:

Rugged Construction: Hard anodized and powder coated cast aluminum housing, billet machined aluminum bezel, and stainless steel hardware ensure exceptional durability.
Weatherproof & Submersible: Exceeds MIL-STD810G and IP69K standards, making it waterproof, submersible to 9 feet, and pressure washable.
Impact Resistant: IK10 compliant for superior impact resistance.
uService: Replaceable lenses and optics for easy maintenance and customization.
CopperDrive: Each LED is driven at 100% for maximum output and thermal management.
5000K Daylight: Reduces driver fatigue with natural, daylight-balanced light.

Kit Includes:

(2) S1 Clear Spot Lights
(2) S1 Clear Wide Cornering Lights
(2) Fog Pocket Brackets
(2) Adapters
(2) Wiring Splitters
(1) Wiring Harness

Specifications (Per Light):

Lumens: 2,375
Wattage/Amps: 20W / 1.45A
Dimensions: 2.1" x 2.1" x 2.1"
Weight: 0.4 lbs
LED Life Expectancy: 49,930 Hours

Warranty:

Limited Lifetime Warranty

Upgrade your GMC Sierra's lighting performance and safety with the Baja Designs Fog Pocket Kit. Order yours today
