Enclosed Thermal Isolation and Maintenance-Free Dry Media

Engineered specifically for the 2017–2019 Ford Super Duty platform powered by the 6.7L Powerstroke V8 turbo diesel, the S&B 75-5085-1D cold air intake addresses the restrictive OEM packaging by swapping the positions of the passenger-side battery and airbox. By placing the airbox directly in line with the front grille air feed, the intake tube runs with minimal bends straight to the turbocharger inlet, reducing intake tract restriction. The kit features a fully enclosed cross-linked polyethylene housing with a clear inspection lid and a multi-layer dry extendable synthetic filter, providing ISO 5011 tested engine protection without requiring filter oils.

Key Features & Benefits

• Optimized Airflow Routing: Positions the airbox directly in line with the factory front inlet via a battery-relocation tray, minimizing tubing bends to accelerate turbo spool.
• Oil-Free Dry Extendable Media: Multi-layer synthetic dry filter element traps fine dust and particulate without filter oil, eliminating the risk of sensor contamination and making cleaning quick and clean.
• Dual Airflow Configuration: Equipped with a primary forward inlet scoop and a secondary auxiliary opening, complete with an included silicone plug to tailor airflow to operating conditions.
• Clear Polycarbonate Sight Lid: Large inspection window allows fast visual checks of filter condition without unbolting or disassembling the intake tract.
• Premium 400°F Silicone Components: Couplers, seals, and filter flange ends made of heavy-duty silicone resist tearing, cracking, and engine bay heat soak under heavy towing loads.

Technical Specifications

• Manufacturer Part Number / SKU: 75-5085-1D (Replaces 75-5085D)
• Engine Platform: 2017–2019 Ford 6.7L Powerstroke V8 Turbo Diesel
• Filter Media Type: Dry Extendable Synthetic Media (Oil-Free, Disposable / Cleanable)
• Housing Style: Fully Enclosed Roto-Molded XLPE Airbox with Clear Lid
• Battery Relocation: Custom Heavy-Duty Replacement Battery Tray Included
• Street Legal Status: 50-State Emissions Legal (CARB EO D-590-21 / D-590-34)
• Warranty: S&B Million Mile Limited Warranty

Vehicle Fitment & Installation Notes

• 2017–2019 Ford F-250 Super Duty Pickup – 6.7L Powerstroke Turbo Diesel
• 2017–2019 Ford F-350 Super Duty Pickup – 6.7L Powerstroke Turbo Diesel
• 2017–2019 Ford F-450 Super Duty Pickup – 6.7L Powerstroke Turbo Diesel
• 2017–2019 Ford F-550 Super Duty Cab & Chassis – 6.7L Powerstroke Turbo Diesel
• Fits Model Years: 2017, 2018, 2019
• Installation Tip: Install the provided replacement battery tray first to relocate the battery inboard, which creates the direct, straight-line channel required to align the airbox and intake tube to the turbocharger inlet.
