The Victor Reinz 02-10419-01 is a complete cylinder head gasket set and top-end installation kit engineered for 1994–2003 7.3 Powerstroke diesel engines. Manufactured by Dana to meet or exceed strict OEM specifications, this kit packages all the critical sealing components required when re-installing cylinder heads after a rebuild, machining, or head stud upgrade. It features multi-piece fiber-and-metal cylinder head gaskets built with integrated combustion fire rings, along with valve cover gaskets, intake/exhaust manifold seals, injector O-rings, and auxiliary top-end sealing components.

Combustion gas leakage into the cooling system, oil seepage across the block deck, coolant consumption, and loss of cylinder compression from a failed or blown factory head gasket are what this kit cures. Whether addressing high-mileage gasket degradation or upgrading fasteners during a high-boost turbo and injector build, replacing only the bare head gaskets often leads to repeat oil or boost leaks. This comprehensive set supplies every matching upper engine seal needed to assemble the top end cleanly and reliably in one box. It is the complete cylinder head gasket and top-end install kit only; cylinder head studs/bolts and liquid gasket sealants are sold separately.

It fits all 1994–2003 7.3 Powerstroke Ford Super Duty trucks, OBS F-Series, Excursions, and E-Series vans.

Fitment

• 1994–1997 Ford F-250 / F-350 OBS 7.3L Powerstroke
• 1999–2003 Ford F-250 Super Duty 7.3L Powerstroke
• 1999–2003 Ford F-350 Super Duty 7.3L Powerstroke
• 1999–2003 Ford F-450 / F-550 Super Duty 7.3L Powerstroke
• 2000–2003 Ford Excursion 7.3L Powerstroke
• 1994–2003 Ford E-Series Vans 7.3L Powerstroke
• Navistar T444E diesel engines
• Direct OEM-spec replacement head installation gasket set
• Multi-piece fiber and metal construction for dependable combustion and fluid sealing
• Cross-references Mahle HS54204A
• Complete top-end head gasket kit only

Ensure both the cylinder head and engine block mating decks are machined flat, thoroughly deburred, and cleaned completely free of oil, carbon, and solvent residue before positioning the head gaskets. Always verify proper gasket orientation over the block alignment dowels; installing head gaskets backward will block vital coolant or high-pressure oil passages and cause immediate engine damage. Install cylinder head bolts or studs completely dry or lubricated strictly per the fastener manufacturer's specifications, following the factory torque sequence in gradual stages to ensure even clamping load across the fire rings.
