7.3 Powerstroke Hydra Tuner Ashtray Bracket | OBS Solutions HM100

Hide a Hydra controller in the factory ashtray instead of hanging it off the dash. The OBS Solutions HM100 is a powder-coated aluminum bracket that clips into the stock ashtray on 1994–1997 F-Series 7.3 Powerstroke trucks. The Hydra display mounts to the bracket, the ashtray still opens and closes, and the tuner stays out of sight until you need it. No dash cutting or custom bezels required.

Key features

• Hidden ashtray mount for a PHP Hydra tuner controller
• Powder-coated aluminum bracket
• Clips into the factory OBS ashtray
• Ashtray still opens and closes
• Clean, low-profile install with no dash cutting
• Includes mounting screws for the Hydra controller
• Made for 1994–1997 F-Series 7.3 Powerstroke

Fitment

• 1994–1997 Ford F-250 / F-350 F-Series with 7.3 Powerstroke
• OBS dash / factory ashtray only

Does not fit 1999–2003 Super Duty or Excursion.

What’s in the box

• OBS Solutions HM100 ashtray bracket
• Screws to attach the Hydra controller

Hydra tuner, ashtray, and PCM are not included. A longer 6-foot ribbon cable is required to reach from the PCM to the ashtray. Some sellers include the cable; confirm before ordering.

Notes & specs

• Brand/part number: OBS Solutions HM100
• Application: Hydra tuner controller mount
• Material: powder-coated aluminum
• Location: factory ashtray
• Required extra: 6-foot Hydra ribbon cable
• Cable note: the longer cable is a replacement, not an add-on extension
• Route the ribbon so it is not pinched when the ashtray opens and closes
• Start the cable at the ashtray and work back toward the parking-brake / PCM area

The HM100 is a mount only. You still need a Hydra tuner and the correct length ribbon cable. If you want a clean, hidden Hydra install in a 1994–1997 7.3 Powerstroke OBS truck, the OBS Solutions HM100 ashtray bracket keeps the controller tucked away without cutting the dash.
