Cyclonic Pre-Filtration and Severe-Duty Engine Protection

Engineered specifically for the 2017–2019 Ford Super Duty platform equipped with the 6.7L Powerstroke V8 turbo diesel, the S&B 75-7001 Truck Particle Separator adapts military-grade cyclonic separation technology to light-truck applications. Designed for agricultural, construction, mining, and extreme off-road driving, this system mounts ahead of the intake to spin incoming air through a series of proprietary vortex tubes. Centrifugal force throws heavy dust, dirt, and sand particles to the perimeter, where an integrated scavenge fan automatically expels them back into the atmosphere, allowing clean air to pass into the intake system.

Key Features & Benefits

• Massive Filter Life Extension: Ejects the vast majority of airborne dust and sand before it reaches the main air filter, dramatically extending cleaning and replacement intervals.
• Military-Grade Cyclonic Separation: Utilizes high-velocity vortex generators to centrifuge particulates out of the primary air path without impeding volume.
• Integrated Scavenge Ejection Fan: High-efficiency, weather-sealed electric scavenge fan continuously evacuates separated dust and debris out of the housing exhaust port.
• Direct-Fit Vehicle Integration: Custom-engineered bracketry and ducting mount seamlessly into factory front-end body locations without permanent body modifications.
• ISO 5011 Tested Durability: Validated against rigorous commercial and military air filtration standards to ensure uncompromised protection in extreme dust environments.

Technical Specifications

• Manufacturer Part Number / SKU: 75-7001
• Engine Platform: 2017–2019 Ford 6.7L Powerstroke V8 Turbo Diesel
• Technology Type: Multi-Vortex Centrifugal Particle Pre-Cleaner with Electric Scavenge Fan
• Housing Material: Heavy-Duty Roto-Molded Polymer Housing with Weather-Sealed Electronics
• Electrical Connection: Plug-and-Play Wiring Harness with Ignition-Triggered Relay
• Standard Compliance: Tested to ISO 5011 Air Filtration Test Standards
• Warranty: S&B Limited Warranty

Vehicle Fitment & Installation Notes

• 2017–2019 Ford F-250 Super Duty Pickup – 6.7L Powerstroke Turbo Diesel
• 2017–2019 Ford F-350 Super Duty Pickup – 6.7L Powerstroke Turbo Diesel
• 2017–2019 Ford F-450 Super Duty Pickup – 6.7L Powerstroke Turbo Diesel
• 2017–2019 Ford F-550 Super Duty Cab & Chassis – 6.7L Powerstroke Turbo Diesel
• Fits Model Years: 2017, 2018, 2019
• Installation Tip: Route the supplied scavenge fan wiring harness away from rotating accessories and high-heat exhaust routing, connecting directly to the designated keyed-ignition circuit so the fan operates only when the engine is running.
